Free NCM-MCI Practice Questions
Each question shows the correct answer and an explanation of why it is right
Question 1 Domain 2 Optimize & Scale
SIMULATION
A company who offers Infrastructure as a Service needs to onboard a new customer. The new customer requires a dedicated cloud plan which tolerates two host failures.
The customer is planning to move current workloads in three waves, with three months between waves starting today:
Wave One: 100 VMs
Wave Two: 50 VMs
Wave Three: 20 VMs
Workload profile is:
vCPU: 4
vRAM: 16 GB
Storage: 200 GB
The service provider company needs to estimate required resources upfront, to accommodate customer requirements, considering also that:
limit the number of total nodes
selected system vendor HPE
selected model DX365-10-G11-NVMe
full-flash node (including NVMe + SSD)
12 months runway
Create and save the scenario as IaaS and export to the desktop, name the file IaaS-requirement.pdf
Note: You must export the PDF to the desktop as IaaS-requirement.pdf to receive any credit.
Here is the step-by-step solution to create and export the capacity planning scenario. This task is performed within Prism Central.
1. Navigate to the Planning Dashboard
From the Prism Central main menu (hamburger icon), navigate to Operations > Planning.
2. Create and Define the Scenario
Click the + Create Scenario button.
In the dialog box:
Scenario Name: IaaS
Scenario Type: Select New Workload
Click Create. This will open the scenario editor.
3. Configure Cluster and Runway Settings
In the 'IaaS' scenario editor, find the Runway setting (top left) and set it to 12 Months.
Find the Cluster configuration tile and click Edit.
Set Number of Host Failures to Tolerate to 2.
Click Save.
4. Define the Workload Profile
In the Workloads section, click the + Add Workload button.
Select Create a new workload profile.
Fill in the VM specifications:
Workload Name: Customer-VM (or similar)
vCPU per VM: 4
Memory per VM: 16 GB
Storage per VM: 200 GB
Click Add.
5. Set the Workload Growth Plan (Waves)
You will be returned to the main scenario editor. In the timeline section ('Workload Plan'), add the VMs:
Wave One (Today):
Click + Add under the 'Today' column.
Select the Customer-VM profile.
Enter 100 VMs.
Click Add.
Wave Two (3 Months):
Click the + icon on the timeline itself.
Set the date to 3 Months from today.
Click + Add under this new '3 Months' column.
Select the Customer-VM profile.
Enter 50 VMs.
Click Add.
Wave Three (6 Months):
Click the + icon on the timeline.
Set the date to 6 Months from today.
Click + Add under this new '6 Months' column.
Select the Customer-VM profile.
Enter 20 VMs.
Click Add.
6. Select the Hardware
In the Hardware configuration tile, click Change Hardware.
In the 'Select Hardware' pane:
Model: Search for and select DX365-10-G11-NVMe.
Note: This model is full-flash by definition, satisfying the requirement.
Click Done. The planner will recalculate the required nodes.
7. Save and Export the Scenario
Click the Save icon (floppy disk) in the top-right corner to save the IaaS scenario.
Click the Export icon (arrow pointing down) in the top-right corner.
Select PDF from the dropdown menu.
A 'Save As' dialog will appear.
Navigate to the Desktop.
Set the file name to IaaS-requirement.pdf.
Click Save.
Question 2 Domain 4 Design Implementation
SIMULATION
Task 7
An administrator has environment that will soon be upgraded to 6.5. In the meantime, they need to implement log and apply a security policy named Staging_Production, such that not VM in the Staging Environment can communicate with any VM in the production Environment,
Configure the environment to satisfy this requirement.
Note: All other configurations not indicated must be left at their default values.
To configure the environment to satisfy the requirement of implementing a security policy named Staging_Production, such that no VM in the Staging Environment can communicate with any VM in the production Environment, you need to do the following steps:
Log in to Prism Central and go to Network > Security Policies > Create Security Policy. Enter Staging_Production as the name of the security policy and select Cluster A as the cluster.
In the Scope section, select VMs as the entity type and add the VMs that belong to the Staging Environment and the Production Environment as the entities. You can use tags or categories to filter the VMs based on their environment.
In the Rules section, create a new rule with the following settings:
Direction: Bidirectional
Protocol: Any
Source: Staging Environment
Destination: Production Environment
Action: Deny
Save the security policy and apply it to the cluster.
This will create a security policy that will block any traffic between the VMs in the Staging Environment and the VMs in the Production Environment. You can verify that the security policy is working by trying to ping or access any VM in the Production Environment from any VM in the Staging Environment, or vice versa. You should not be able to do so.



Question 3 Domain 2 Optimize & Scale
SIMULATION
The DB team is requesting an SQL database instance and has requested it be configured for best performance. This VM has been migrated from a 3 tier solution into Nutanix.
The database VM hosts 4 databases, each set to a 20 GB limit. Logs are expected to not grow beyond 20 GB and should be limited to within 25% to avoid runaway processes. Do not configure more storage than is needed.
The VM that has been migrated is identified as sql3532. Once the VM has been properly reconfigured, the DBA team will reconfigure the OS and database.
The VM should be configured as per KB-3532.
While this VM is being tested, make sure it is the first VM to power up in the event the node it is on goes down.
To maximize performance, ensure as much of the VM as possible will be kept on SSD drives.
Note: The VM does not need to be powered on. The VM should remain on the default container and should not be configured with a volume group. No network is required at this time.
Here is the step-by-step solution to reconfigure the sql3532 virtual machine.
This task is performed from the Prism Element interface for the cluster the VM is on (e.g., Cluster 1).
1. Locate and Update the VM
From the Prism Element main dashboard, navigate to the VM view.
Find the VM named sql3532 in the VM table.
Select the checkbox next to sql3532 and click the Update button.
2. Configure HA Priority and Flash Mode
In the 'Update VM' dialog, configure the HA and SSD performance settings:
HA Priority:
Find the VM High Availability section.
Select the High Priority radio button. This ensures it is one of the first VMs to power on during an HA event.
Flash Mode (SSD Performance):
Scroll down to the Flash Mode section.
Check the box to Enable Flash Mode. This pins the VM's vDisks to the SSD tier, satisfying the requirement to keep as much of the VM as possible on SSDs, especially since it's on the default (hybrid) container.
3. Reconfigure Disks (per KB-3532)
While still in the 'Update VM' dialog, scroll to the Disks section to add the new data and log disks. The key to 'best performance' (KB-3532) is to place Data and Logs on separate vSCSI controllers.
(The VM already has an OS disk, which we will assume is on scsi.0.)
Add Data Disk:
Click the + Add New Disk button.
Storage Container: default (as required).
Size: 80 GB (for the 4 x 20 GB databases).
Bus Type: SCSI.
Device Index: 1. (This creates a new vSCSI controller, scsi.1, for the data disk).
Click Add.
Add Log Disk:
Click the + Add New Disk button.
Storage Container: default (as required).
Size: 20 GB.
Bus Type: SCSI.
Device Index: 2. (This creates a third vSCSI controller, scsi.2, for the log disk).
Click Add.
4. Save Configuration
After adding the disks and setting HA/Flash Mode, click the main Save button at the bottom of the 'Update VM' dialog.
The VM is now configured with high availability, its storage is pinned to SSD, and its disk layout follows performance best practices by separating the OS, Data, and Log I/O paths onto three different controllers.
Topic 2, Performance Based Questions Set 2
Environment
You have been provisioned a dedicated environment for your assessment which includes the following:
Workstation
* windows Server 2019
* All software/tools/etc to perform the required tasks
* Nutanix Documentation and whitepapers can be found in desktop\files\Documentation
* Note that the workstation is the system you are currently togged into
Nutanix Cluster
* There are three clusters provided. The connection information for the relevant cluster will be displayed to the high of the question Please make sure you are working on the correct cluster for each item Please ignore any licensing violations
* Cluster A is a 3-node cluster with Prism Central 2022.6 where most questions will be performed
* Cluster B is a one-node cluster and has one syslog item and one security item to perform
* Cluster D is a one-node duster with Prism Central 5.17 and has a security policy item to perform
Important Notes
* If the text is too small and hard to read, or you cannot see an of the GUI. you can increase/decrease the zoom of the browser with CTRL + ,and CTRL + (the plus and minus keys)
You will be given 3 hours to complete the scenarios for Nutanix NCMMCI
Once you click the start button below, you will be provided with:
- A Windows desktop A browser page with the scenarios and credentials (Desktop\instructions)
Notes for this exam delivery:
The browser can be scaled lo Improve visibility and fit all the content on the screen.
- Copy and paste hot-keys will not work Use your mouse for copy and paste.
- The Notes and Feedback tabs for each scenario are to leave notes for yourself or feedback for
- Make sure you are performing tasks on the correct components.
- Changing security or network settings on the wrong component may result in a falling grade.
- Do not change credentials on an component unless you are instructed to.
- All necessary documentation is contained in the Desktop\Files\Documentation directory
Get the complete NCM-MCI question set
$20$40
Question 4 Domain 2 Optimize & Scale
SIMULATION
An administrator is working to create a VM using Nutanix V3 API calls with the following specifications.
VM specifications:
vCPUs: 2
Memory: 8Gb
Disk Size: 50Gb
Cluster: Cluster 1
Network: default-net
Branding must be disabled on the VM
The API call is failing, indicating an issue with the payload:
"": [
"'metadata' is a required property",
"'spec' is a required property"
],
"message": "Request could not be processed.",
"reason": "INVALID_REQUEST"
The body is saved in desktop\API_Create_VM.txt.
Correct any issues in the text file that would prevent it from creating the VM. Also ensure the VM will be created as specified and make sure it is saved for re-use using that filename.
Deploy the VM through the API.
Note: Do not power on the VM.
Here is the step-by-step solution to correct the API payload and deploy the VM.
This task is performed using the REST API Explorer within Prism Central.
1. Get Required UUIDs
To create a VM, you first need the unique IDs (UUIDs) for the target cluster and network.
From the Prism Central dashboard, click the question mark (?) icon in the top-right corner and select REST API Explorer.
Find Cluster 1 UUID:
In the API Explorer, search for and select the clusters/list (POST) endpoint.
In the Body field, paste a simple filter: { 'kind': 'cluster' }
Click Send.
In the 'Response' body, find the entry for Cluster 1 and copy its metadata.uuid value.
Find default-net UUID:
Search for and select the subnets/list (POST) endpoint.
In the Body field, paste: { 'kind': 'subnet' }
Click Send.
In the 'Response' body, find the entry where spec.name is default-net and copy its metadata.uuid value.
2. Correct the API Payload File
The error message ''metadata' is a required property' and ''spec' is a required property' indicates the JSON in the file is malformed and missing the required root-level objects. The file content also does not match the VM specifications.
On the desktop, open API_Create_VM.txt in Notepad.
Delete all existing text in the file (including the POST Call and Body: lines).
Paste the following corrected and complete JSON payload into the file.
Replace <UUID_for_Cluster_1> and <UUID_for_default-net> with the actual UUIDs you copied in the previous step.
JSON
{
'spec': {
'name': 'API_VM_Task15',
'resources': {
'power_state': 'OFF',
'num_sockets': 2,
'num_vcpus_per_socket': 1,
'memory_size_mib': 8192,
'disk_list': [
{
'disk_size_mib': 51200,
'device_properties': {
'device_type': 'DISK'
}
}
],
'nic_list': [
{
'subnet_reference': {
'kind': 'subnet',
'uuid': '<UUID_for_default-net>'
}
}
],
'guest_customization': {
'is_overridable': true,
'override_branding': true
}
},
'cluster_reference': {
'kind': 'cluster',
'uuid': '<UUID_for_Cluster_1>'
}
},
'metadata': {
'kind': 'vm'
}
}
Save and close the API_Create_VM.txt file.
Correction Summary:
JSON Structure: The original file was malformed. The new payload provides the required spec and metadata objects at the root level.
vCPUs: Set to 2 sockets (2 vCPUs total).
Memory: Set to 8192 MiB (8 GB).
Disk: Set to 51200 MiB (50 GB) and removed the unneeded CDROM.
Cluster/Network: Placeholders are added for the required UUIDs.
Branding: guest_customization.override_branding: true is added to disable branding for the VM.
3. Deploy the VM via API
Return to the REST API Explorer.
Search for and select the vms (POST) endpoint (the one with the description 'Create a new vm').
Open the corrected API_Create_VM.txt file, copy its entire contents (which now includes your specific UUIDs).
Paste the complete JSON payload into the Body field of the vms (POST) endpoint.
Click Send.
The API will return a 202 Accepted response, and the VM will be created (and remain powered off) on Cluster 1.
Question 5 Domain 3 Security
SIMULATION
An administrator needs to configure a new write-intensive MS-SQL VM on Cluster 1.
VM specifications:
vCPU: 12
vRAM: 128GB
Storage: 100 GB OS, 750 GB Data
Create the VM and any objects needed in the current environment to meet requirements, maximizing performance for the production environment. Include NEWSQL in the name of any new objects.
Production environment:
4 nodes
Each node has two 8-core CPUs
Each node has 1024 GB RAM
Storage: 4 7.16 TB SSD Disks and 8 8 TB HDD disks
Make sure the VM is configured for maximum performance for the production environment.
Note: Network configuration is not required at this time. Do not power on the VM.
Here is the step-by-step solution to create the high-performance SQL VM on Cluster 1.
This task requires two phases: first, creating a new all-flash storage container, and second, creating the VM with a specific vNUMA and disk controller configuration for maximum performance.
1. Access Cluster 1 Prism Element
From the main Prism Central dashboard, navigate to Hardware > Clusters.
Find Cluster 1 in the list and click its name. This will open the specific Prism Element login page for that cluster.
Log in to Cluster 1's Prism Element interface.
2. Create the All-Flash Storage Container
To maximize performance for a 'write-intensive' workload on a hybrid cluster, the data and log disks must be placed on an all-flash container.
In the Cluster 1 PE interface, click the gear icon (Settings) in the top-right corner.
From the left-hand menu, select Storage.
Click the + Storage Container button.
Fill in the basic details:
Name: NEWSQL_Flash_Container
Click Advanced Settings.
Scroll down to the Storage Tier section.
Select the SSD radio button. This pins all data in this container to the SSD tier, ensuring all-flash performance.
Click Save.
3. Create and Configure the VM
Now, create the VM, applying vNUMA and multi-SCSI controller best practices.
From the main PE dashboard, navigate to the VM view.
Click the + Create VM button.
Enter the compute details. This configuration is critical for vNUMA performance, as it tells the VM's guest OS about the underlying physical NUMA topology (2 CPUs with 8 cores each).
Name: NEWSQL_VM
vCPUs: 12
Number of Sockets: 2
Cores per vCPU: 6 (This creates a 2-socket, 6-core VM, totaling 12 vCPUs)
Memory: 128 GB
Scroll down to the Disks section and add the OS disk:
Click + Add New Disk.
Storage Container: Select the default (hybrid) container.
Size: 100 GB
Bus: SCSI
Device Index: 0 (This will be scsi.0)
Click Add.
Add the Data disk (on its own controller for parallel processing):
Click + Add New Disk.
Storage Container: Select NEWSQL_Flash_Container.
Size: 750 GB
Bus: SCSI
Device Index: 1 (This creates a new controller, scsi.1)
Click Add.
Add a Log disk (on its own controller, a best practice for 'write-intensive' SQL):
Click + Add New Disk.
Storage Container: Select NEWSQL_Flash_Container.
Size: 100 GB (A common size for a log disk)
Bus: SCSI
Device Index: 2 (This creates a third controller, scsi.2)
Click Add.
Review the configuration: You should now have three disks attached, each on a separate controller (scsi.0, scsi.1, scsi.2). This provides the maximum I/O performance.
Ensure the Power on VM after creation box is unchecked.
Click Save.
Question 6 Domain 1 Monitoring & Troubleshooting
SIMULATION
The Database team is reporting performance degradation for a business-critical application on Saturdays.
The team is requesting monitoring of processor, memory and storage utilization for the cluster for the application: SQL01, SQL02.
The report should contain views for the following:
At the cluster level, only for the Cluster 1: The maximum percentage of CPU used
At the VM level, including any future VM with the prefix SQL: The maximum time taken, maximum percentage of time a VM waits to use the physical CPU, out of the total CPU
The report should run on Sundays at 12:00 AM for the previous 7 days. The report should show when completed.
Create a report named SQL_Batch_Saturday that meets these requirements.
Generate an instance of the report named SQL_Batch_Saturday as a CSV and save the file.
Note: You must name the report SQL_Batch_Saturday to receive any credit. Any other name will not be accepted. SMTP is not configured.
Here is the step-by-step solution to create and run the report, performed entirely within Prism Central.
1. Create the Analysis Session
First, we will build the charts and entities for the report using the Analysis tool.
From the Prism Central main menu, navigate to Operations > Analysis.
Click the + New Session button.
Add the required entities:
In the 'Entities' search box, type Cluster 1 and select Cluster: Cluster 1.
In the 'Entities' search box, type SQL01 and select VM: SQL01.
In the 'Entities' search box, type SQL02 and select VM: SQL02.
Click Add Charts > New Chart to add the Cluster CPU chart:
Title: Cluster 1 Max CPU Usage
Entity Type: Cluster
Metric: Cluster CPU Usage %
Aggregation: Select Maximum.
Click Add.
Click Add Charts > New Chart to add the VM CPU Ready Time chart:
Title: VM Max CPU Ready Time
Entity Type: VM
Metric: CPU Ready Time %
Aggregation: Select Maximum.
Click Add.
2. Save and Configure the Report
Now, save the session as a report and configure it to dynamically include all VMs with the SQL prefix.
Click the Save as Report icon (the bookmark icon in the upper right).
Name the report SQL_Batch_Saturday and click Save.
Navigate to Operations > Reports.
Find the SQL_Batch_Saturday report you just created and click its name to open the report editor.
In the Entities tile, click the Edit (pencil) icon.
By default, it will list 'Cluster 1', 'SQL01', and 'SQL02'.
Change the VM selection:
Select the radio button for All VMs prefixed with.
In the text box, enter SQL.
Ensure 'Cluster 1' is still listed under 'Clusters'.
Click Save.
3. Schedule the Report
While still in the report editor for SQL_Batch_Saturday, click the Schedule button.
Configure the schedule:
Recurrence: Weekly
Repeat on: Sunday
Start Time: 12:00 AM
Time Range: Previous 7 Days
Configure the notification (as SMTP is not available):
Expand the Notification Settings section.
Check the box for Notify when ready (this enables the bell icon notification).
Ensure 'Email Report' is not checked.
Click Save.
4. Generate and Save the CSV Instance
Finally, run the report now and download the CSV as requested.
Navigate back to the main Operations > Reports list.
Select the checkbox next to SQL_Batch_Saturday.
Click the Actions dropdown and select Run Now.
In the dialog, confirm the time range (e.g., 'Last 7 Days') and click Run.
Click the Report Instances tab.
Wait for the report instance 'SQL_Batch_Saturday' to finish running (the status will change from 'Running' to Succeeded).
Once it has succeeded, click the Download (arrow) icon for that instance.
Select the CSV format.
Save the file to the desktop.
Question 7 Domain 3 Security
SIMULATION
Task 14
The application team has requested several mission-critical VMs to be configured for disaster recovery. The remote site (when added) will not be managed by Prism Central. As such, this solution should be built using the Web Console.
Disaster Recovery requirements per VM:
Mkt01
RPO: 2 hours
Retention: 5 snapshots
Fin01
RPO: 15 minutes
Retention: 7 days
Dev01
RPO: 1 day
Retention: 2 snapshots
Configure a DR solution that meets the stated requirements.
Any objects created in this item must start with the name of the VM being protected.
Note: the remote site will be added later
To configure a DR solution that meets the stated requirements, you can follow these steps:
Log in to the Web Console of the source cluster where the VMs are running.
Click on Protection Domains on the left menu and click on Create Protection Domain.
Enter a name for the protection domain, such as PD_Mkt01, and a description if required. Click Next.
Select Mkt01 from the list of VMs and click Next.
Select Schedule Based from the drop-down menu and enter 2 hours as the interval. Click Next.
Select Remote Site from the drop-down menu and choose the remote site where you want to replicate the VM. Click Next.
Enter 5 as the number of snapshots to retain on both local and remote sites. Click Next.
Review the protection domain details and click Finish.
Repeat the same steps for Fin01 and Dev01, using PD_Fin01 and PD_Dev01 as the protection domain names, and adjusting the interval and retention values according to the requirements.



What the Nutanix NCM-MCI Exam Covers
Exam domains verified against the Official Nutanix NCM-MCI exam guide, last checked November 2026.
Domain 1 Monitoring & Troubleshooting
Use prism analysis tools to identify performance issues; Perform health check and collect logs; Interpret alerts and take appropriate actions for remediation; Create reports and custom metrics to monitor the environment
Sample question from this domain above Q6
Domain 2 Optimize & Scale
Utilize runway scenarios to evaluate workload changes; Implement workload-based best practices; Utilize APIs to automate management tasks
Domain 3 Security
Perform advanced cluster configuration; Implement Flow Network Security; Configure advanced log management; Implement authentication according to best practices; Implement encryption, including KMS
Domain 4 Design Implementation
Configure Nutanix products and features to meet business needs; Configure networking to meet business needs; Align cluster configuration to requirements; Configure cluster policies and features for availability and resiliency; Create/Configure VMs based on workload requirements
Sample question from this domain above Q2
Domain 5 Business Continuity
Analyze Business Continuity and Disaster Recovery strategies and align them with organizational missions. Ensure BCDR strategies meet regulatory needs and satisfy particular organizational requirements.
NCM-MCI Exam FAQ
Common questions about the exam itself
What is the difference between NCM-MCI and the lower-level NCP-MCI certification?
Why is NCM-MCI considered harder than other Nutanix certifications?
How long should I spend preparing for NCM-MCI?
What happens on NCM-MCI exam day?
Which objective area gives candidates the most trouble?
How long does the NCM-MCI certification remain valid?
What job roles typically pursue NCM-MCI certification?
Can I retake the NCM-MCI exam if I fail?
What prerequisites do I need before taking NCM-MCI?
How does NCM-MCI fit into the Nutanix certification path?
Other Nutanix Exams
Free practice questions for more Nutanix certification exams
